Motor of main spindle:

3Hp-3phases-4P

 Main spindle speed:

3600 rpm

Maximum distance between 2 bearings

 650 mm

 Closest distance between 2 bearings

 50 mm

Number of drill head:

06

Oscillating displacement of the table:

70mm

Table dimensions:

700x250 mm

drilling journey

80 mm

Displacement of the table up-down:

 100 mm

 Drill dimension:

Ø 1.5 - Ø13 mm

Machine dimensions (LxWxH):

905 x 750 x 920 mm

 Machine net weight:

210 Kg

Timber species:  Softwood / Hardwood

Operating voltage:

380V ± 5%, 50HZ
